MICHELIN CARGOXBIB®
Enhanced endurance for heavy loads at low pressures.
- Soil Protection
- Profitability
- Productivity
- Steel Crown Belts
Cargoxbib
Soil Protection
Fuel Savings
Increase your productivity
Steel Belts
RELATED SERVICES AND SOLUTIONS
Technical Specifications
| Product | MICHELIN CARGOXBIB - 600/50R22.5 |
|---|---|
| Overall Diameter | 1181 mm / 46 inch |
| Recommended Wheels | AG20.00(H2)x22.5 |
| Minimum dual spacing | 760 mm / 29.92 inch |
| Tread depth | 17 mm / 0.7/32 nds |
| Loaded radius | 510 mm |
| CAI | 048429 |
| MSPN | 94336 |
| Load Index | 159 |
| Speed Index | D |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
1 15 |
1.3 19 |
1.5 22 |
1.9 28 |
2.2 32 |
2.5 36 |
2.8 41 |
3.1 45 |
3.4 49 |
3.7 54 |
4 58 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) | |||||||||||
|
10 km/h 6 mph |
3570 7871 |
4170 9193 |
4575 10086 |
5375 11850 |
5980 13184 |
6475 14275 |
6755 14892 |
7035 15510 |
7320 16138 |
7600 16755 |
7880 17372 |
|
25 km/h 16 mph |
3020 6658 |
3570 7871 |
3940 8686 |
4670 10296 |
5225 11519 |
5675 12511 |
5920 13051 |
6170 13603 |
6415 14143 |
6665 14694 |
6910 15234 |
|
40 km/h 25 mph |
2640 5820 |
3105 6845 |
3420 7540 |
4040 8907 |
4510 9943 |
4890 10781 |
5105 11255 |
5315 11718 |
5525 12181 |
5740 12655 |
5950 13118 |
|
50 km/h 31 mph |
2340 5159 |
2760 6085 |
3035 6691 |
3595 7926 |
4010 8841 |
4355 9601 |
4540 10009 |
4730 10428 |
4915 10836 |
5105 11255 |
5290 11662 |
|
65 km/h 40 mph |
1950 4299 |
2290 5049 |
2520 5556 |
2970 6548 |
3315 7308 |
3595 7926 |
3750 8267 |
3910 8620 |
4065 8962 |
4225 9315 |
4380 9656 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to change.
Technical data is subject to change without prior notice.
