MICHELIN MEGAXBIB^®

Combines
Floaters

Loading… tires for this product

MICHELIN MEGAXBIB^®

Combines
Floaters

Excellent solution for harvesters and heavy equipment.

Load capacity
Endurance
Comfort
Steel Crown Belts

Technical Specifications Find a Dealer

All sizes (14)

Steer/All Position

620/75 R26 166A8/166B TL
750/50 R26 160A8/154D TL
750/65 R26 171A8/171B TL
620/75 R30 168A8/168B TL
650/75 R32 172A8/172B TL
800/65 R32 178A8/178B TL
800/70 R32 181A8/181B TL
900/60 R32 181A8/181B TL
1050/50 R32 178A8 TL M28
1050/50 R32 184A8/184B TL T2
620/75 R34 170A8/170B TL
710/75 R34 178A8/178B TL
520/85 R42 162A8/162B TL
620/70 R42 166A8/166B TL

Technical Specifications

M+S	No
3PMSF	No
RFID	No
Overall Diameter	1602 mm
Recommended Wheels	DW20B (A)
Approved Wheels	DW18L
Tread depth	46/32 nds
Catalog Number	614320
CAI	614320
MSPN	89936
Load Index	166
Speed Index	A8

Pressures (bar and psi) & Loads (kg and lbs)

Take the load and type of work to be done into account when adjusting the pressure**

bar psi	1 15	1.3 19	1.6 23	1.9 28	2.2 32	2.3 33	2.4 35	2.5 36	2.6 38	2.7 39	2.8 41	2.9 42	3.2 46	3.5 51	3.8 55
(kg - lbs)
10 km/h 6 mph	3910 8620	4405 9710	4900 10805	5315 11720	5730 12630	5870 12940	6010 13250	6150 13560	6285 13855	6425 14165	6565 14475	6700 14770	7120 15695	7535 16610	7950 17525
10 km/h Cyc 6 mph Cyc	4410 9720	4820 10625	5230 11530	5745 12665	6260 13800	6435 14185	6605 14560	6775 14935	6950 15320	7120 15695	7290 16070	7465 16455	7980 17595	8495 18730	9010 19865
25 km/h 15 mph	3170 6990	3610 7960	4050 8930	4395 9690	4735 10440	4850 10690	4965 10945	5080 11200	5195 11455	5310 11705	5425 11960	5535 12205	5880 12965
30 km/h 20 mph	3060 6745	3480 7670	3900 8600	4230 9325	4565 10065	4675 10305	4785 10550	4895 10790	5005 11035	5115 11275	5230 11530	5340 11775	5670 12500
40 km/h 25 mph	2860 6305	3250 7165	3640 8025	3950 8710	4265 9405	4365 9625	4470 9855	4575 10085	4680 10320	4780 10540	4885 10770	4990 11000	5300 11685
50 km/h 30 mph	2860 6305	3250 7165	3640 8025	3950 8710	4265 9405	4365 9625	4470 9855	4575 10085	4680 10320	4780 10540	4885 10770	4990 11000	5300 11685

bar

psi

1.3

1.6

1.9

2.2

2.3

2.4

2.5

2.6

2.7

2.8

2.9

3.2

3.5

3.8

(kg - lbs)

10 km/h

6 mph

3910

8620

4405

9710

4900

10805

5315

11720

5730

12630

5870

12940

6010

13250

6150

13560

6285

13855

6425

14165

6565

14475

6700

14770

7120

15695

7535

16610

7950

17525

10 km/h Cyc

6 mph Cyc

4410

9720

4820

10625

5230

11530

5745

12665

6260

13800

6435

14185

6605

14560

6775

14935

6950

15320

7120

15695

7290

16070

7465

16455

7980

17595

8495

18730

9010

19865

25 km/h

15 mph

3170

6990

3610

7960

4050

8930

4395

9690

4735

10440

4850

10690

4965

10945

5080

11200

5195

11455

5310

11705

5425

11960

5535

12205

5880

12965

30 km/h

20 mph

3060

6745

3480

7670

3900

8600

4230

9325

4565

10065

4675

10305

4785

10550

4895

10790

5005

11035

5115

11275

5230

11530

5340

11775

5670

12500

40 km/h

25 mph

2860

6305

3250

7165

3640

8025

3950

8710

4265

9405

4365

9625

4470

9855

4575

10085

4680

10320

4780

10540

4885

10770

4990

11000

5300

11685

50 km/h

30 mph

2860

6305

3250

7165

3640

8025

3950

8710

4265

9405

4365

9625

4470

9855

4575

10085

4680

10320

4780

10540

4885

10770

4990

11000

5300

11685

**IMPORTANT

The inflation pressure must always be appropriate for the load per tyre, the speed of travel and the work to be done. Our recommendations above are provided subject to changes

made after the date of publication of these tables (December 2020). Technical data is subject to change without prior notice.

MICHELIN MEGAXBIB^®

Excellent solution for harvesters and heavy equipment.

LOAD CAPACITY

ENDURANCE

COMFORT

STEEL CROWN BELTS

HIGH CAPACITY

Michelin MegaXBib for floaters and terragators
