MICHELIN X®TRA LOAD PROTECT
The Michelin E4 radial tire has high load-carrying capacity and provides excellent protection for haul trucks working in demanding quarry environments.
Vehicle Type
Rigid Dump Truck
Rigid Dump Truck
Usage of Application
Surface Mining, Quarries, Mixed Surface
Surface Mining
Quarries
Mixed Surface
Why choose the MICHELIN X®TRA LOAD PROTECT tire?
Excellent protection for trucks working in demanding quarry environments.
Explore Michelin technology and innovation designed to support your business, reducing your costs while respecting the environment.
Load Capacity
8-11% higher pay load (1,2)
Productivity
More distance in an hour (3)
Tire Life
+7-8% wear life (4,5)
MICHELIN X®TRA LOAD PROTECT Technology
MICHELIN X®TRA LOAD PROTECT Tire Reviews
Tire Technical Specifications
Tech Specs
| Product | MICHELIN XTRA LOAD PROTECT - 18.00R33 |
|---|---|
| Overall Diameter | 1888 mm / 74 inch |
| Section Width | 498 mm / 20 inch |
| Loaded radius | 857 mm |
| Seat diameter | 33 |
| Rolling circumference | 5713 mm / 225 inch |
| Tread depth | 63 mm / 80/32 nds |
| Compound | A4 |
| Weight | 473 kg / 1043 lbs |
| Recommended Wheels | 13.00/2.5 |
| TRA code | E-4 |
| TKPH | 194 |
| Max Overall Section Width | 498 mm / 20 inch |
| Min Dual Spacing | 598 mm / 23.54 inch |
| CAI | 646057 |
| MSPN | 89058 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
4 58 |
4.5 65 |
5 73 |
5.5 80 |
6 87 |
6.5 94 |
7 102 |
7.5 109 |
8 116 |
|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) Transport | |||||||||
|
Standard |
7950 17527 |
8700 19180 |
9400 20723 |
10150 22377 |
10900 24030 |
11700 25794 |
12150 26786 |
12650 27888 |
13100 28881 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tech Specs
Tech Specs
| Product | MICHELIN XTRA LOAD PROTECT - 18.00R33 |
|---|---|
| Overall Diameter | 1888 mm / 74 inch |
| Section Width | 498 mm / 20 inch |
| Loaded radius | 857 mm |
| Seat diameter | 33 |
| Rolling circumference | 5713 mm / 225 inch |
| Tread depth | 63 mm / 80/32 nds |
| Compound | A4 |
| Weight | 473 kg / 1043 lbs |
| Recommended Wheels | 13.00/2.5 |
| TRA code | E-4 |
| TKPH | 194 |
| Max Overall Section Width | 498 mm / 20 inch |
| Min Dual Spacing | 598 mm / 23.54 inch |
| CAI | 646057 |
| MSPN | 89058 |
Pressure (bar and psi) & Load (kg and lbs)
Factor the load and type of work when adjusting tire pressure**
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
4 58 |
4.5 65 |
5 73 |
5.5 80 |
6 87 |
6.5 94 |
7 102 |
7.5 109 |
8 116 |
|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) Transport | |||||||||
|
Standard |
7950 17527 |
8700 19180 |
9400 20723 |
10150 22377 |
10900 24030 |
11700 25794 |
12150 26786 |
12650 27888 |
13100 28881 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tire Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
Product Legal Information
(1) Compared to Bridgestone® VMTP and VRLS tires, and MICHELIN® X®QUARRY™ in size S 18.00R33. Actual results may vary. (Sources: Databook Bridgestone® OTR 2018 and Databook MICHELIN® 2017.) (2) Compared to the same dimension on Bridgestone® VMTP and VRLS - Source Databook Bridgestone® OTR 2016 and on MICHELIN® X®QUARRY™ S - Source Databook MICHELIN® 2017.(3) Compared to MICHELIN® X®QUARRY™ S tires. Actual results may vary.(4) Compared to MICHELIN® X®QUARRY™ in size S 18.00 R33 and based on measurements in field tests and measurements carried out using the FARO method, certified by the Michelin® Technology Center. Actual results may vary. (5) Compared to the same size on MICHELIN® X®QUARRY™ S, field test measurements certified by the Michelin® Technology Center, from 2015 to 2017.
