MICHELIN XDR3 EXTRA LOAD tire is designed for surface mining, offering up to a 12.6% increase in maximum truck payload and a 15% increase in TKPH.
MICHELIN XDR3 EXTRA LOAD
Increase your maximum truck payload by up to 12.6% (1) vs. Michelin XDR3, TKPH = 15% (1)
Vehicle Type
Rigid Dump Truck
Rigid Dump Truck
Usage of Application
Surface Mining, Quarries
Surface Mining
Quarries
MICHELIN MEMS is a TPMS solution for mining vehicles to remotely monitor activity, performance and maintenance throughout your tire lifecycle. Find the benefits and MEMS solution that works for you:
Why choose the MICHELIN XDR3 EXTRA LOAD tire?
Boost payload, boost productivity.
Explore Michelin technology and innovation designed to support your business, reducing your costs while respecting the environment.
Load Capacity
Increase in load capacity by 12.6% with better load distribution(1)
Stronger cables, new plies, robust structure.
Tire Life
A slower wear rate
A slower wear rate thanks to a new mixing process with innovative compounds.(1)
Load Capacity
Increase in load capacity by 12.6% with better load distribution(1)
Stronger cables and robust structure provide the increase in load capacity.
MICHELIN XDR3 EXTRA LOAD Tire Reviews
Tire Technical Specifications
Tech Specs
| Product | MICHELIN XDR3 EXTRA LOAD - 53/80R63 |
|---|---|
| Overall Diameter | 3806 mm / 150 inch |
| Section Width | 1357 mm / 53 inch |
| Loaded radius | 1661 mm |
| Seat diameter | 63 |
| Rolling circumference | 11324 |
| Tread depth | 110 mm / 138/32 nds |
| Compound | MB |
| Weight | 4860 kg / 10714 lbs |
| Recommended Wheels | 36.00/5.0 [5.5] |
| Approved Wheels | 36.00/5.0 [5]-38.00/5.0 [5.5]-38.00/5.0 [5] |
| TRA code | E-4 |
| TKPH | 1824 |
| Max Overall Section Width | 1357 mm / 53 inch |
| Min Dual Spacing | 1637 mm / 64.45 inch |
| CAI | 664323 |
| MSPN | 17762 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
7 102 |
7.25 105 |
7.5 109 |
|---|---|---|---|
| (kg - lbs) Transport | |||
|
Standard |
90000 198416 |
92500 203928 |
95000 209439 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tech Specs
Tech Specs
| Product | MICHELIN XDR3 EXTRA LOAD - 53/80R63 |
|---|---|
| Overall Diameter | 3806 mm / 150 inch |
| Section Width | 1357 mm / 53 inch |
| Loaded radius | 1661 mm |
| Seat diameter | 63 |
| Rolling circumference | 11324 |
| Tread depth | 110 mm / 138/32 nds |
| Compound | MB |
| Weight | 4860 kg / 10714 lbs |
| Recommended Wheels | 36.00/5.0 [5.5] |
| Approved Wheels | 36.00/5.0 [5]-38.00/5.0 [5.5]-38.00/5.0 [5] |
| TRA code | E-4 |
| TKPH | 1824 |
| Max Overall Section Width | 1357 mm / 53 inch |
| Min Dual Spacing | 1637 mm / 64.45 inch |
| CAI | 664323 |
| MSPN | 17762 |
Pressure (bar and psi) & Load (kg and lbs)
Factor the load and type of work when adjusting tire pressure**
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
7 102 |
7.25 105 |
7.5 109 |
|---|---|---|---|
| (kg - lbs) Transport | |||
|
Standard |
90000 198416 |
92500 203928 |
95000 209439 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tire Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
Related Services and Solutions
Product Legal Information
(1) Comparison with the MICHELIN® XDR® 3, size 53/80R63. Actual results may vary.
