The MICHELIN XDR3 + tire is engineered for extreme durability in mining operations. Its advanced tread design provides enhanced resistance to wear and cuts.
MICHELIN XDR3+
Get More Tire Life: At Least 4%(1) More with the MB4 compound. At least 6%(1) more with the MB compound.
Vehicle Type
Rigid Dump Truck
Rigid Dump Truck
Usage of Application
Surface Mining, Quarries
Surface Mining
Quarries
MICHELIN MEMS is a TPMS solution for mining vehicles to remotely monitor activity, performance and maintenance throughout your tire lifecycle. Find the benefits and MEMS solution that works for you:
Why choose the MICHELIN XDR3+ tire?
Long lasting innovations.
Explore Michelin technology and innovation designed to support your business, reducing your costs while respecting the environment.
Durability
Michelin Multilayer Technology
Layer one is optimized for front axles for the first cycle of the tire’s life and is designed to handle steering and braking force. Layer two underneath is optimized for rear axles for the second cycle of the tire’s life and is designed to handle braking force and torque transmission (1).
Tire Life
Improved Wear Resistance Due to Second Generation of Revolutionary Compounds
Two new compounds: MB4 and MB.
Exclusive new mixing process.
Much more homogeneous mix that leads to a slower wear rate.
Superior level of carbon black dispersion, leading to increased wear resistance.
MICHELIN XDR3+ Tire Reviews
Tire Technical Specifications
Tech Specs
| Product | MICHELIN XDR3+ - 40.00R57 |
|---|---|
| Overall Diameter | 3580 mm / 141 inch |
| Section Width | 1127 mm / 44 inch |
| Loaded radius | 1578 mm |
| Seat diameter | 57 |
| Rolling circumference | 10714 |
| Tread depth | 98 mm / 125/32 nds |
| Compound | MB4 |
| Weight | 3720 kg / 8201 lbs |
| Recommended Wheels | 29.00/6.0 [5.7] |
| Approved Wheels | 29.00/6.0 [5.2]-32.00/6.0 |
| TRA code | E-4 |
| TKPH | 960 |
| Max Overall Section Width | 1127 mm / 44 inch |
| Min Dual Spacing | 1365 mm / 53.74 inch |
| CAI | 151477 |
| MSPN | 38891 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
4.5 65 |
5 73 |
5.5 80 |
6 87 |
6.25 91 |
6.5 94 |
6.75 98 |
7 102 |
7.25 105 |
|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) Transport | |||||||||
|
Standard |
47750 105271 |
51850 114310 |
55950 123349 |
60000 132277 |
61400 135364 |
62800 138450 |
64200 141537 |
65600 144623 |
67000 147710 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tech Specs
Tech Specs
| Product | MICHELIN XDR3+ - 40.00R57 |
|---|---|
| Overall Diameter | 3580 mm / 141 inch |
| Section Width | 1127 mm / 44 inch |
| Loaded radius | 1578 mm |
| Seat diameter | 57 |
| Rolling circumference | 10714 |
| Tread depth | 98 mm / 125/32 nds |
| Compound | MB4 |
| Weight | 3720 kg / 8201 lbs |
| Recommended Wheels | 29.00/6.0 [5.7] |
| Approved Wheels | 29.00/6.0 [5.2]-32.00/6.0 |
| TRA code | E-4 |
| TKPH | 960 |
| Max Overall Section Width | 1127 mm / 44 inch |
| Min Dual Spacing | 1365 mm / 53.74 inch |
| CAI | 151477 |
| MSPN | 38891 |
Pressure (bar and psi) & Load (kg and lbs)
Factor the load and type of work when adjusting tire pressure**
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
4.5 65 |
5 73 |
5.5 80 |
6 87 |
6.25 91 |
6.5 94 |
6.75 98 |
7 102 |
7.25 105 |
|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) Transport | |||||||||
|
Standard |
47750 105271 |
51850 114310 |
55950 123349 |
60000 132277 |
61400 135364 |
62800 138450 |
64200 141537 |
65600 144623 |
67000 147710 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tire Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
Related Services and Solutions
Product Legal Information
(1) Compared to the MICHELIN® XDR® 3 tire. Average performance by mine site. Projected improvement in tire life based on the result of 13 field performance placement customer mine sites. Actual results may vary. - 40.00R57 MB TIRE , - 40.00R57 MB4 TIRE, - 50/90R57 MB TIRE, - 50/90R57 MB4 TIRE, - 53/80R63 MB TIRE, - 53/80R63 MB4 TIRE, - 59/80R63 MB TIRE, - 59/80R63 MB4 TIRE.(1) Tires are designed to be rotated to the rear axles to increase tire life.
