The MICHELIN XDT tire is engineered for surface mining and quarry applications, providing exceptional traction and durability. Its deep, aggressive tread design ensures excellent ground contact.
MICHELIN XDT (Mining)
Long-distance tire providing excellent grip and traction in difficult conditions: -Excellent traction -Excellent resistance to hard wear and tear -Long-lasting tread design with regular wear
Vehicle Type
Rigid Dump Truck
Rigid Dump Truck
Usage of Application
Surface Mining, Quarries
Surface Mining
Quarries
MICHELIN MEMS is a TPMS solution for mining vehicles to remotely monitor activity, performance and maintenance throughout your tire lifecycle. Find the benefits and MEMS solution that works for you:
Why choose the MICHELIN XDT (Mining) tire?
Excellent grip and traction in difficult conditions
Explore Michelin technology and innovation designed to support your business, reducing your costs while respecting the environment.
Traction
Excellent lateral grip and traction
Maximum ground contact area
• Reduced slipping
• Tread blocks that grip the ground
Deep, aggressive tread surface
Durability
Designed to resist cuts, hard wear and tear
Protective sidewall bands
Square shoulders
Thick tread surface
Tire Life
Excellent life and uptime
Deep tread depth (E4)
Long service life
Non-directional tread design
MICHELIN XDT (Mining) Tire Reviews
Tire Technical Specifications
Tech Specs
| Product | MICHELIN XDT - 33.00R51 |
|---|---|
| Overall Diameter | 3040 mm / 120 inch |
| Section Width | 911 mm / 36 inch |
| Loaded radius | 1365 mm |
| Seat diameter | 51 |
| Rolling circumference | 9161 |
| Tread depth | 87 mm / 109/32 nds |
| Compound | B |
| Weight | 2166 kg / 4775 lbs |
| Recommended Wheels | 24.00/5.0 [4.4] |
| Approved Wheels | 24.00/5.0 [3.9] |
| TRA code | E-4 |
| TKPH | 930 |
| Max Overall Section Width | 911 mm / 36 inch |
| Min Dual Spacing | 1107 mm / 43.58 inch |
| CAI | 123961 |
| MSPN | 53227 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
3.5 51 |
4 58 |
4.5 65 |
5 73 |
5.5 80 |
6 87 |
6.5 94 |
7 102 |
|---|---|---|---|---|---|---|---|---|
| (kg - lbs) Transport | ||||||||
|
Standard |
25550 56328 |
28200 62170 |
30800 67902 |
33450 73745 |
36600 80689 |
38750 85429 |
40100 88405 |
41400 91271 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tech Specs
Tech Specs
| Product | MICHELIN XDT - 33.00R51 |
|---|---|
| Overall Diameter | 3040 mm / 120 inch |
| Section Width | 911 mm / 36 inch |
| Loaded radius | 1365 mm |
| Seat diameter | 51 |
| Rolling circumference | 9161 |
| Tread depth | 87 mm / 109/32 nds |
| Compound | B |
| Weight | 2166 kg / 4775 lbs |
| Recommended Wheels | 24.00/5.0 [4.4] |
| Approved Wheels | 24.00/5.0 [3.9] |
| TRA code | E-4 |
| TKPH | 930 |
| Max Overall Section Width | 911 mm / 36 inch |
| Min Dual Spacing | 1107 mm / 43.58 inch |
| CAI | 123961 |
| MSPN | 53227 |
Pressure (bar and psi) & Load (kg and lbs)
Factor the load and type of work when adjusting tire pressure**
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
3.5 51 |
4 58 |
4.5 65 |
5 73 |
5.5 80 |
6 87 |
6.5 94 |
7 102 |
|---|---|---|---|---|---|---|---|---|
| (kg - lbs) Transport | ||||||||
|
Standard |
25550 56328 |
28200 62170 |
30800 67902 |
33450 73745 |
36600 80689 |
38750 85429 |
40100 88405 |
41400 91271 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tire Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
