MICHELIN XF™
Radial steel construction to increase tire life and traction.
- Radial Tire
- Comfort
- Versatility
- 100% Steel Construction
XF
Radial
Comfort
Versatility
Steel belts
RELATED SERVICES AND SOLUTIONS
Technical Specifications
| Product | MICHELIN XF - 445/70R19.5 |
|---|---|
| Overall Diameter | 1110 mm / 44 inch |
| Recommended Wheels | 14.00x19.5 |
| Minimum dual spacing | 585 mm / 23.03 inch |
| Tread depth | 18 mm / 0.7/32 nds |
| Loaded radius | 499 mm |
| CAI | 489102 |
| Load Index | 173 |
| Speed Index | A8 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
3.5 51 |
3.8 55 |
4 58 |
4.4 64 |
4.8 70 |
5.2 75 |
5.6 81 |
6 87 |
6.2 90 |
6.4 93 |
6.6 96 |
6.8 99 |
7 102 |
7.2 104 |
7.5 109 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) | |||||||||||||||
|
0 km/h 0 mph |
6580 14506 |
7060 15565 |
7385 16281 |
8025 17692 |
8665 19103 |
9310 20525 |
9950 21936 |
10595 23358 |
10915 24063 |
11235 24769 |
11555 25474 |
11875 26180 |
12200 26896 |
12520 27602 |
13000 28660 |
|
10 km/h 6 mph |
4050 8929 |
4345 9579 |
4545 10020 |
4940 10891 |
5335 11762 |
5730 12632 |
6125 13503 |
6520 14374 |
6715 14804 |
6915 15245 |
7110 15675 |
7310 16116 |
7505 16546 |
7705 16987 |
8000 17637 |
|
20 km/h 12 mph |
3585 7904 |
3850 8488 |
4025 8874 |
4375 9645 |
4725 10417 |
5075 11188 |
5425 11960 |
5775 12732 |
5950 13118 |
6125 13503 |
6300 13889 |
6475 14275 |
6650 14661 |
6825 15047 |
7085 15620 |
|
30 km/h 19 mph |
3420 7540 |
3670 8091 |
3840 8466 |
4170 9193 |
4505 9932 |
4840 10670 |
5175 11409 |
5510 12147 |
5675 12511 |
5840 12875 |
6010 13250 |
6175 13614 |
6345 13988 |
6510 14352 |
6760 14903 |
|
35 km/h 22 mph |
3355 7397 |
3600 7937 |
3765 8300 |
4090 9017 |
4420 9744 |
4745 10461 |
5075 11188 |
5400 11905 |
5565 12269 |
5730 12632 |
5895 12996 |
6055 13349 |
6220 13713 |
6385 14077 |
6630 14617 |
|
40 km/h 25 mph |
3290 7253 |
3530 7782 |
3690 8135 |
4010 8841 |
4335 9557 |
4655 10263 |
4975 10968 |
5295 11673 |
5455 12026 |
5615 12379 |
5780 12743 |
5940 13095 |
6100 13448 |
6260 13801 |
6500 14330 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to change.
Technical data is subject to change without prior notice.
