MICHELIN XHA 2
This radial loader tire with reinforced sidewall construction and deeper, patented tread design provides excellent damage resistance, enhanced traction and reduced vibration for construction and quarry applications.
Why choose the MICHELIN XHA 2 tire?
Longevity
Durability
Intensity
MICHELIN XHA 2 Technology
Tire Technical Specifications
Tech Specs
| Product | MICHELIN XHA2 - 17.5R25 |
|---|---|
| Overall Diameter | 1342 mm / 53 inch |
| Section Width | 459 mm / 18 inch |
| Loaded radius | 583 mm |
| Seat diameter | 25 |
| Rolling circumference | 3995 mm / 157 inch |
| Tread depth | 29 mm / 35/32 nds |
| Weight | 140 kg / 309 lbs |
| Recommended Wheels | 14.00/1.5 |
| Approved Wheels | 13.00/1.4 DC-14.00/1.5 DC |
| TRA code | L-3 |
| Max Overall Section Width | 459 mm / 18 inch |
| CAI | 717546 |
| MSPN | 48885 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
2 29 |
2.5 36 |
3 44 |
3.5 51 |
4.25 62 |
4.5 65 |
|---|---|---|---|---|---|---|
| (kg - lbs) grader | ||||||
|
All Axles |
2800 6173 |
3250 7165 |
3650 8047 |
|||
| (kg - lbs) loader | ||||||
|
Front laden |
4550 10031 |
5100 11244 |
5700 12566 |
6250 13779 |
7100 15653 |
7350 16204 |
|
Rear unladen |
3650 8047 |
4100 9039 |
4550 10031 |
5000 11023 |
5700 12566 |
5900 13007 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tech Specs
| Product | MICHELIN XHA2 - 17.5R25 |
|---|---|
| Overall Diameter | 1342 mm / 53 inch |
| Section Width | 459 mm / 18 inch |
| Loaded radius | 583 mm |
| Seat diameter | 25 |
| Rolling circumference | 3995 mm / 157 inch |
| Tread depth | 29 mm / 35/32 nds |
| Weight | 140 kg / 309 lbs |
| Recommended Wheels | 14.00/1.5 |
| Approved Wheels | 13.00/1.4 DC-14.00/1.5 DC |
| TRA code | L-3 |
| Max Overall Section Width | 459 mm / 18 inch |
| CAI | 717546 |
| MSPN | 48885 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
2 29 |
2.5 36 |
3 44 |
3.5 51 |
4.25 62 |
4.5 65 |
|---|---|---|---|---|---|---|
| (kg - lbs) grader | ||||||
|
All Axles |
2800 6173 |
3250 7165 |
3650 8047 |
|||
| (kg - lbs) loader | ||||||
|
Front laden |
4550 10031 |
5100 11244 |
5700 12566 |
6250 13779 |
7100 15653 |
7350 16204 |
|
Rear unladen |
3650 8047 |
4100 9039 |
4550 10031 |
5000 11023 |
5700 12566 |
5900 13007 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tire Product Sheet and Databook
Find the technical and commercial specifications downloadable documents below.
(1) Compared to premium competitors (Goodyear® RT-3B, TL3A+ and BRIDGESTONE® VMT et VJT); road tests in real-life conditions were conducted by Michelin over 5 years, from 2012 to 2017, in Eastern and Western Europe, China, and the South Asia-Pacific region, using 170 tires of the same size (25 R25 et 29.5 R25) under the same use conditions. (2) Measurements certified by the Michelin Technology Center using XAO software; comparison between MICHELIN® X® HA 2™ 26.5 R25 tires and BRIDGESTONE® VMT and BRIDGESTONE® VJT tires of the same size.(3) Certified test by the Michelin Technology Center at the Almeria Circuit in Spain, July 2016. Comparison between MICHELIN XHA2 tires and BRIDGESTONE® VJT tires of the same size. All the tires were tested following the same protocols and configuration, including the number of tires tested. Test organized using a CAT 966 M, at 9 mph with a 12,000 metric ton load and a 58 psi tire pressure.
