MICHELIN XLD D2 (Construction)
The directional Michelin L5 Radial tire for wheel loaders designed to provide hidh levels of traction, protection and stability with a cushioned ride for operator comfort.
Why choose the MICHELIN XLD D2 (Construction) tire?
Durability
Tire Life
Load Capacity
Self-Cleaning
MICHELIN XLD D2 (Construction) Technology
Tire Technical Specifications
Tech Specs
| Product | MICHELIN XLDD2 - 17.5R25 |
|---|---|
| Overall Diameter | 1406 mm / 55 inch |
| Section Width | 454 mm / 18 inch |
| Loaded radius | 619 mm |
| Seat diameter | 25 |
| Rolling circumference | 4206 mm / 166 inch |
| Tread depth | 63 mm / 80/32 nds |
| Compound | A |
| Weight | 207.15 kg / 457 lbs |
| Recommended Wheels | 14.00/1.5 |
| TRA code | L-5 |
| Max Overall Section Width | 454 mm / 18 inch |
| CAI | 123317 |
| MSPN | 37608 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
2 29 |
2.5 36 |
3 44 |
3.5 51 |
4.25 62 |
4.5 65 |
5 73 |
5.5 80 |
|---|---|---|---|---|---|---|---|---|
| (kg - lbs) grader | ||||||||
|
All Axles |
2800 6173 |
3250 7165 |
3650 8047 |
|||||
| (kg - lbs) underground-transport-machine | ||||||||
|
All Axles |
4250 9370 |
4750 10472 |
5600 12346 |
5800 12787 |
6300 13889 |
6700 14771 |
||
| (kg - lbs) loader | ||||||||
|
Front laden |
4550 10031 |
5100 11244 |
5700 12566 |
6250 13779 |
7100 15653 |
7350 16204 |
||
|
Rear unladen |
3650 8047 |
4100 9039 |
4550 10031 |
5000 11023 |
5700 12566 |
5900 13007 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
Tech Specs
| Product | MICHELIN XLDD2 - 17.5R25 |
|---|---|
| Overall Diameter | 1406 mm / 55 inch |
| Section Width | 454 mm / 18 inch |
| Loaded radius | 619 mm |
| Seat diameter | 25 |
| Rolling circumference | 4206 mm / 166 inch |
| Tread depth | 63 mm / 80/32 nds |
| Compound | A |
| Weight | 207.15 kg / 457 lbs |
| Recommended Wheels | 14.00/1.5 |
| TRA code | L-5 |
| Max Overall Section Width | 454 mm / 18 inch |
| CAI | 123317 |
| MSPN | 37608 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
2 29 |
2.5 36 |
3 44 |
3.5 51 |
4.25 62 |
4.5 65 |
5 73 |
5.5 80 |
|---|---|---|---|---|---|---|---|---|
| (kg - lbs) grader | ||||||||
|
All Axles |
2800 6173 |
3250 7165 |
3650 8047 |
|||||
| (kg - lbs) underground-transport-machine | ||||||||
|
All Axles |
4250 9370 |
4750 10472 |
5600 12346 |
5800 12787 |
6300 13889 |
6700 14771 |
||
| (kg - lbs) loader | ||||||||
|
Front laden |
4550 10031 |
5100 11244 |
5700 12566 |
6250 13779 |
7100 15653 |
7350 16204 |
||
|
Rear unladen |
3650 8047 |
4100 9039 |
4550 10031 |
5000 11023 |
5700 12566 |
5900 13007 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes
Technical data is subject to change without prior notice.
