Michelin XTRA DEFEND E4/L4 Tires | MICHELIN Commercial Tires United States

Finalize my selection 0

You have not selected a product

E4**/L4** B Speed level for (65 and 80 series) to travel site-to-site on the road with higher torque transmission for loaders/ADT

Find a Dealer

Why choose the MICHELIN XTRA DEFEND E4/L4 tire?

Designed to resist

Explore Michelin technology and innovation designed to support your business, reducing your costs while respecting the environment.

Productivity

New load capacity⁽¹⁾ for high torque wheel-loader & ADT

Casing designed at load capacity 25 750 kg / 56 779 lbs ⁽²⁾ with increased protection and up to 14 km in one hour at high temperature up to 47°C.

Durability

Reinforced crown and summit resistance to aggression.

Up to +50%⁽³⁾ of mass metal, thicker summit with up to 5 plies conception with specific aggression rubber resistance.

Versatility

Reinforced casing and summit conception for ADT/WHL applications

One product for 2 main machines: a stronger bead for high torque wheel-loader and reinforced crown and summit for ADT applications.

MICHELIN XTRA DEFEND E4/L4 Technology

The radial tire - The Michelin innovation that revolutionized tire construction

Sold under the name Michelin X®, this tire was a real breakthrough thanks to its exceptional performance: incredible longevity (it lasted 2 to 4 times longer than a conventional tire), greater safety, and, above all, reduced vehicle fuel consumption.

Tire Technical Specifications

23.5R25 E4** L4** G4* 185B TL
26.5R25 E4** L4** G4* 193B TL
29.5R25 E4** L4** 200B TL
750/65R25 E4** L4* G4* 190B TL
775/65R29 E4** L4** 195B TL
875/65R29 E4** L4** 203B TL

Tech Specs

Product	MICHELIN XTRA DEFEND E4/L4 - 23.5R25
Overall Diameter	1619 mm / 64 inch
Section Width	617 mm / 24 inch
Loaded radius	729 mm
Seat diameter	25
Rolling circumference	5586 mm / 220 inch
Tread depth	54 mm / 67/32 nds
Load Index	201
Weight	365 kg / 805 lbs
Recommended Wheels	19.50/2.5
TRA code	E-4,L-4
TKPH	192
Max Overall Section Width	617 mm / 24 inch
CAI	723646
MSPN	80181

Pressure (bar and psi) & Load (kg and lbs)

Factor the load and type of work when adjusting tire pressure**

bar psi	2 29	2.5 36	3 44	3.5 51	3.75 54	4 58	4.5 65	5 73	5.5 80
(kg - lbs) grader
All Axles	4850 10692	5250 11574	6000 13228	6750 14881	7130 15719	7500 16535	8200 18078
(kg - lbs) articulated-dump-truck
All Axles	5650 12456	6380 14065	7100 15653	7800 17196	8175 18023	8550 18850	9250 20393	9950 21936	10350 22818
(kg - lbs) loader
Front laden	8100 17857	9100 20062	10150 22377	11150 24582	11650 25684	12150 26786	13350 29432	13900 30644	14500 31967
Rear unladen	6500 14330	7300 16094	8100 17857	8900 19621	9300 20503	9700 21385	10700 23589	11160 24604	11600 25574

bar

psi

2.5

3.5

3.75

4.5

5.5

(kg - lbs) grader

All Axles

4850

10692

5250

11574

6000

13228

6750

14881

7130

15719

7500

16535

8200

18078

(kg - lbs) articulated-dump-truck

All Axles

5650

12456

6380

14065

7100

15653

7800

17196

8175

18023

8550

18850

9250

20393

9950

21936

10350

22818

(kg - lbs) loader

Front laden

8100

17857

9100

20062

10150

22377

11150

24582

11650

25684

12150

26786

13350

29432

13900

30644

14500

31967

Rear unladen

6500

14330

7300

16094

8100

17857

8900

19621

9300

20503

9700

21385

10700

23589

11160

24604

11600

25574

**IMPORTANT

The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes

Technical data is subject to change without prior notice.

Tech Specs

Product	MICHELIN XTRA DEFEND E4/L4 - 23.5R25
Overall Diameter	1619 mm / 64 inch
Section Width	617 mm / 24 inch
Loaded radius	729 mm
Seat diameter	25
Rolling circumference	5586 mm / 220 inch
Tread depth	54 mm / 67/32 nds
Load Index	201
Weight	365 kg / 805 lbs
Recommended Wheels	19.50/2.5
TRA code	E-4,L-4
TKPH	192
Max Overall Section Width	617 mm / 24 inch
CAI	723646
MSPN	80181

Pressure (bar and psi) & Load (kg and lbs)

Factor the load and type of work when adjusting tire pressure**

bar psi	2 29	2.5 36	3 44	3.5 51	3.75 54	4 58	4.5 65	5 73	5.5 80
(kg - lbs) grader
All Axles	4850 10692	5250 11574	6000 13228	6750 14881	7130 15719	7500 16535	8200 18078
(kg - lbs) articulated-dump-truck
All Axles	5650 12456	6380 14065	7100 15653	7800 17196	8175 18023	8550 18850	9250 20393	9950 21936	10350 22818
(kg - lbs) loader
Front laden	8100 17857	9100 20062	10150 22377	11150 24582	11650 25684	12150 26786	13350 29432	13900 30644	14500 31967
Rear unladen	6500 14330	7300 16094	8100 17857	8900 19621	9300 20503	9700 21385	10700 23589	11160 24604	11600 25574

bar

psi

2.5

3.5

3.75

4.5

5.5

(kg - lbs) grader

All Axles

4850

10692

5250

11574

6000

13228

6750

14881

7130

15719

7500

16535

8200

18078

(kg - lbs) articulated-dump-truck

All Axles

5650

12456

6380

14065

7100

15653

7800

17196

8175

18023

8550

18850

9250

20393

9950

21936

10350

22818

(kg - lbs) loader

Front laden

8100

17857

9100

20062

10150

22377

11150

24582

11650

25684

12150

26786

13350

29432

13900

30644

14500

31967

Rear unladen

6500

14330

7300

16094

8100

17857

8900

19621

9300

20503

9700

21385

10700

23589

11160

24604

11600

25574

**IMPORTANT

The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes

Technical data is subject to change without prior notice.

Tire Product Sheet and Databook

Find the technical and commercial specifications downloadable documents below.

Product sheet Michelin Xtra Defend E4/L4

Data Book Michelin Compact Equipment Tires
