Tire with exceptional total cost of ownership, for airport ground support equipment.

Find a Dealer

Why choose the MICHELIN XZR tire?

The solution for airport ground support equipment.

Explore Michelin technology and innovation designed to support your business, reducing your costs while respecting the environment.

Speed Rating

Capable of reaching up to 31 mph ⁽¹⁾

The radial technology, tread pattern and specific rubber compounds allows for higher speeds.

Confidence

Exceptional grip for short distance braking

The radial structure and multi-block pattern provides maximum ground footprint.

Durability

Limit machine downtime

Radial tubeless construction to prevent punctures and damages.

MICHELIN XZR Technology

The radial tire - The Michelin innovation that revolutionized tire construction

Sold under the name Michelin X®, this tire was a real breakthrough thanks to its exceptional performance: incredible longevity (it lasted 2 to 4 times longer than a conventional tire), greater safety, and, above all, reduced vehicle fuel consumption.

Tire Technical Specifications

Tech Specs

Product	MICHELIN XZR - 6.00R9
Overall Diameter	530 mm / 21 inch
Section Width	164 mm / 6 inch
Loaded radius	241 mm
Seat diameter	9
Rolling circumference	1605
Tread depth	10 mm / 13/32 nds
Weight	11.71 kg / 26 lbs
Recommended Wheels	4.00E
TRA code	IND-3
Max Overall Section Width	164 mm / 6 inch
Min Dual Spacing	192 mm / 7.56 inch
CAI	110206
MSPN	68425

Pressure (bar and psi) & Load (kg and lbs)

Factor the load and type of work when adjusting tire pressure**

bar psi	6 87	8 116	10 145
(kg - lbs) counterbalanced-lift-truck-steer-wheel
0 km/h 0 mph	1590 3505	1890 4167	2190 4828
25 km/h 16 mph	1050 2315	1250 2756	1450 3197
35 km/h 22 mph	980 2161	1160 2557	1350 2976
40 km/h 25 mph	940 2072	1120 2469	1300 2866
50 km/h 31 mph	890 1962	1050 2315	1220 2690
(kg - lbs) Counterbalanced Lift Truck - load wheel
10 km/h 6 mph	1370 3020	1630 3594	1890 4167
25 km/h 16 mph	1370 3020	1630 3594	1890 4167
35 km/h 22 mph	1320 2910	1570 3461	1820 4012

bar

psi

116

145

(kg - lbs) counterbalanced-lift-truck-steer-wheel

0 km/h

0 mph

1590

3505

1890

4167

2190

4828

25 km/h

16 mph

1050

2315

1250

2756

1450

3197

35 km/h

22 mph

980

2161

1160

2557

1350

2976

40 km/h

25 mph

940

2072

1120

2469

1300

2866

50 km/h

31 mph

890

1962

1050

2315

1220

2690

(kg - lbs) Counterbalanced Lift Truck - load wheel

10 km/h

6 mph

1370

3020

1630

3594

1890

4167

25 km/h

16 mph

1370

3020

1630

3594

1890

4167

35 km/h

22 mph

1320

2910

1570

3461

1820

4012

**IMPORTANT

The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes

Technical data is subject to change without prior notice.

Tech Specs

Product	MICHELIN XZR - 6.00R9
Overall Diameter	530 mm / 21 inch
Section Width	164 mm / 6 inch
Loaded radius	241 mm
Seat diameter	9
Rolling circumference	1605
Tread depth	10 mm / 13/32 nds
Weight	11.71 kg / 26 lbs
Recommended Wheels	4.00E
TRA code	IND-3
Max Overall Section Width	164 mm / 6 inch
Min Dual Spacing	192 mm / 7.56 inch
CAI	110206
MSPN	68425

Pressure (bar and psi) & Load (kg and lbs)

Factor the load and type of work when adjusting tire pressure**

bar psi	6 87	8 116	10 145
(kg - lbs) counterbalanced-lift-truck-steer-wheel
0 km/h 0 mph	1590 3505	1890 4167	2190 4828
25 km/h 16 mph	1050 2315	1250 2756	1450 3197
35 km/h 22 mph	980 2161	1160 2557	1350 2976
40 km/h 25 mph	940 2072	1120 2469	1300 2866
50 km/h 31 mph	890 1962	1050 2315	1220 2690
(kg - lbs) Counterbalanced Lift Truck - load wheel
10 km/h 6 mph	1370 3020	1630 3594	1890 4167
25 km/h 16 mph	1370 3020	1630 3594	1890 4167
35 km/h 22 mph	1320 2910	1570 3461	1820 4012

bar

psi

116

145

(kg - lbs) counterbalanced-lift-truck-steer-wheel

0 km/h

0 mph

1590

3505

1890

4167

2190

4828

25 km/h

16 mph

1050

2315

1250

2756

1450

3197

35 km/h

22 mph

980

2161

1160

2557

1350

2976

40 km/h

25 mph

940

2072

1120

2469

1300

2866

50 km/h

31 mph

890

1962

1050

2315

1220

2690

(kg - lbs) Counterbalanced Lift Truck - load wheel

10 km/h

6 mph

1370

3020

1630

3594

1890

4167

25 km/h

16 mph

1370

3020

1630

3594

1890

4167

35 km/h

22 mph

1320

2910

1570

3461

1820

4012

**IMPORTANT

The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to changes

Technical data is subject to change without prior notice.

Tire Product Sheet and Databook

Find the technical and commercial specifications downloadable documents below.

Product sheet Michelin XZR

Michelin Earthmover, Off-Road, and Industrial Tires Limited Warranty

Michelin 6-Month No Flat Guarantee

Data Book Material Handling
