MICHELIN POWER DIGGER
Bias ply tire resistant to cuts with great stability.
- Long Service Life
- Damage and Cut Resistant
- Stability
- Dual Fitment for Wheeled Excavators (2)
Power Digger
Long service life
Sidewall thickness
Stability
Power digger
RELATED SERVICES AND SOLUTIONS
Technical Specifications
| Product | MICHELIN POWER DIGGER - 10.00-20 |
|---|---|
| Overall Diameter | 1050 mm / 41 inch |
| Recommended Wheels | 7.5T20 |
| Minimum dual spacing | 341 mm / 13.43 inch |
| Tread depth | 15 mm / 0.6/32 nds |
| Loaded radius | 488 mm |
| CAI | 263208 |
| MSPN | 03227 |
| Load Index | 165 |
| Speed Index | A2 |
Pressure (bar and psi) & Load (kg and lbs)
|
bar psi |
4 58 |
4.4 64 |
4.8 70 |
5.2 75 |
5.6 81 |
6 87 |
6.4 93 |
6.6 96 |
6.8 99 |
7 102 |
7.2 104 |
7.4 107 |
7.6 110 |
7.8 113 |
8 116 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (kg - lbs) | |||||||||||||||
|
0 km/h 0 mph |
4000 8818 |
4380 9656 |
4760 10494 |
5140 11332 |
5520 12170 |
5900 13007 |
6260 13801 |
6440 14198 |
6620 14595 |
6800 14991 |
6980 15388 |
7160 15785 |
7340 16182 |
7515 16568 |
7690 16954 |
|
10 km/h 6 mph |
2670 5886 |
2925 6449 |
3180 7011 |
3430 7562 |
3685 8124 |
3940 8686 |
4180 9215 |
4300 9480 |
4425 9755 |
4545 10020 |
4665 10285 |
4785 10549 |
4905 10814 |
5030 11089 |
5150 11354 |
|
20 km/h 12 mph |
2130 4696 |
2330 5137 |
2535 5589 |
2735 6030 |
2940 6482 |
3140 6923 |
3330 7341 |
3425 7551 |
3520 7760 |
3615 7970 |
3710 8179 |
3805 8389 |
3900 8598 |
3995 8807 |
4090 9017 |
|
30 km/h 19 mph |
1745 3847 |
1910 4211 |
2075 4575 |
2240 4938 |
2405 5302 |
2570 5666 |
2725 6008 |
2805 6184 |
2885 6360 |
2965 6537 |
3040 6702 |
3120 6878 |
3200 7055 |
3285 7242 |
3370 7430 |
|
35 km/h 22 mph |
1630 3594 |
1785 3935 |
1940 4277 |
2095 4619 |
2250 4960 |
2405 5302 |
2555 5633 |
2625 5787 |
2700 5952 |
2775 6118 |
2850 6283 |
2925 6449 |
2995 6603 |
3065 6757 |
3135 6911 |
|
50 km/h 31 mph |
1360 2998 |
1560 3439 |
1760 3880 |
1960 4321 |
2160 4762 |
2360 5203 |
2505 5523 |
2575 5677 |
2650 5842 |
2720 5997 |
2790 6151 |
2865 6316 |
2935 6471 |
3005 6625 |
3075 6779 |
**IMPORTANT
The inflation pressure must always be appropriate for the load per tire, the speed of travel and the work to be done. Our recommendations above are provided subject to change.
Technical data is subject to change without prior notice.
